Pin Ultrasonic Welder

This machine replaces soldering processes for semiconductor pins, offering automated needle insertion and welding with high strength and reliability. It requires no cleaning and ensures low resistance.
Highlights:
Automated positioning and welding up to 1.8kW power.
Non-destructive tensile testing for quality assurance.
Suitable for pins of 2-25mm² area.
Applications: Semiconductor devices, microelectronics, new energy battery modules.

Email

Core Features

Process Replacement Capability:
Effectively replaces traditional welding processes with advanced ultrasonic technology
Automated Operation System:
Integrated automated needle insertion, precision positioning, and intelligent welding capabilities
Performance Advantages:

Superior welding strength with exceptional reliability
Low resistance characteristics ensuring high thermal conduction efficiency
Elimination of post-process cleaning requirements

Technical Specifications

Category	Specification Details
Welding Parameters
Welding Mode	Time/Energy/Height triple-mode selection
Amplitude Range	50% ~ 100% adjustable range
Maximum Power	1.8kW (Ultrasonic system)
Operation Modes
Loading Mode	Semi-automatic/Fully automatic options
Z-axis Stroke	≥60mm working range
Control Systems
Positioning System	Visual positioning with guidance technology
Motion System	Fully servo-controlled precision mechanism
Quality Assurance
Monitoring System	Multi-dimensional data monitoring with process control
MES Integration	Available for production management systems
Optional Accessories	Scanning gun, dust-removal system available

System Integration

Smart Manufacturing Compatibility:
Seamless integration with existing production lines through standardized interfaces
Precision Engineering:
Advanced motion control system ensures consistent welding quality across production batches
Maintenance Efficiency:
Minimal maintenance requirements with self-diagnostic capabilities for reduced downtime

Application Advantages

Process Optimization: 40% faster cycle times compared to conventional methods
Quality Consistency: ±0.5% welding parameter accuracy
Energy Efficiency: 30% reduction in power consumption versus traditional systems

This comprehensive ultrasonic welding solution represents the latest advancement in joining technology, offering unprecedented precision, reliability, and efficiency for modern manufacturing requirements. The system's modular design allows for customization to specific production needs while maintaining the highest standards of quality and performance.
