Product Title TS8296 Benchtop Spectrophotometer
The TS8296 Benchtop Spectrophotometer delivers laboratory-grade color measurement with exceptional accuracy, featuring a D/8 optical geometry and dual-array CMOS sensor for precise reflectance and transmittance analysis. It supports simultaneous SCI/SCE measurement, covers a 360-780nm wavelength range, and offers four switchable apertures (25.4mm to 4mm) for versatile sample handling. With high repeatability (ΔEab ≤0.01) and inter-instrument consistency (ΔEab ≤0.12), it includes a 7-inch touchscreen, full-spectrum LED+UV lighting, and compliance with international standards. Ideal for plastics, textiles, paints, and cosmetics, it enables efficient color quality control and data management via PC software.
Download
Overview
The TS8296 Benchtop Spectrophotometer is an advanced instrument designed for accurate color analysis in both reflective and transparent samples. Utilizing independent spectroscopic core technology, it ensures reliable performance for industries requiring stringent color consistency, such as plastics, electronics, paints, textiles, and printing. With a robust design and user-friendly interface, it facilitates precise color transfer and quality control in laboratory settings.
Key Features
High-Precision Optical System
The instrument adopts a D/8 structure (diffuse illumination, 8° reception), supporting simultaneous SCI/SCE measurement for comprehensive data capture. Its dual-array CMOS image sensor provides high sensitivity and a broad spectral response, ensuring rapid results (2.4s per measurement) with repeatability within ΔE*ab 0.01. The integration of a full-spectrum LED light source (360-780nm) and UV option eliminates spectral gaps, enhancing accuracy for fluorescent materials.
Versatile Measurement Capabilities
Equipped with four automatically identifiable apertures—25.4mm, 15mm, 8mm, and 4mm—the TS8296 adapts to various sample sizes. The apertures ensure flexibility for diverse applications, from large surfaces to small components.
This multi-aperture design allows users to switch seamlessly based on sample requirements, supported by automatic calibration for consistency.
Advanced Color Management
The spectrophotometer supports multiple color spaces (e.g., CIE LAB, LCh, Munsell) and 41 illuminants (e.g., D65, A, CWF), enabling customization for specific conditions. It calculates indices like whiteness (ASTM E313), yellowness (ASTM D1925), and metamerism, with data displayed on a 7-inch capacitive touchscreen. PC-compatible SQCX software facilitates report generation, color difference analysis, and mass data storage (up to 40,000 samples).
Technical Specifications
Optical Geometry: Reflectance: di:8°/de:8°; Transmittance: di:0°/de:0°
Wavelength Range: 360-780nm, with 10nm intervals and 10nm semi-bandwidth
Measuring Time: ~2.4s (SCI/SCE simultaneous: ~5s)
Dimensions: 370x300x200mm; weight: ~9.6kg
Power: AC 24V adapter; illuminant lifespan: 5 years/3 million measurements
Connectivity: USB, Bluetooth, print serial port
Compliance: Meets CIE No.15, ISO7724-1, ASTM E1164, etc.
Applications
The TS8296 is widely used across industries for color quality assurance. Its precision benefits sectors like plastics, where color consistency is critical for consumer products.
In paints and inks, it ensures batch-to-batch uniformity.
Printing and packaging rely on it for accurate color matching.
Automotive and textile industries use it for material validation.
Cosmetics and food sectors apply it for quality checks.
Optional accessories like micro-printers and petri dishes expand its utility for specialized testing.
Reliability and Support
Each unit includes a metrological verification report, traceable to national standards, ensuring data authority. With an intuitive interface and multi-language support (e.g., English, Chinese), the TS8296 simplifies operation while maintaining industrial durability for long-term use.
