HG60 Economic Gloss Meter – Professional 60° Gloss Measurement for Quality Control

Introduction to the HG60 Gloss Meter

The HG60 Economic Gloss Meter, independently developed by 3nh with full intellectual property rights, offers a professional solution for gloss measurement in industrial and laboratory settings. Designed in compliance with international standards such as ISO 2813, GB/T 9754, ASTM D523, and ASTM D2457, this device ensures reliable performance for a wide range of surface gloss evaluations. Its compact and ergonomic design, combined with advanced hardware configurations, makes it ideal for quick inspections and long-term quality control tasks.

Key Features and Benefits

• High-Resolution Display & Multi-Data Comparison:

  The 3.5-inch TFT screen clearly presents up to 5 measurement results simultaneously, enabling efficient data comparison and reducing remeasurement needs. This is particularly useful for batch testing and quality assurance workflows.




• One-Touch Multi-Angle Measurement (Optional):

  With a single button, users can obtain gloss values from the same location without repositioning the device, enhancing consistency and saving time.




• Automatic Calibration & High Accuracy:

  The built-in auto-calibration function ensures ready-to-use precision. With a resolution of 0.1 GU and repeatability within ±0.1 GU (low-gloss range), the HG60 guarantees dependable results across various materials.




• Extended Battery Life & Portability:

  Equipped with a 3200mAh lithium-ion battery, the meter supports over 10,000 measurements on a single charge (within 8 hours). Its lightweight (350g) and portable design (160×75×90mm) facilitate field use.




• PC Connectivity & Extended Software Functions:

  Via USB connection, users can link the HG60 to a computer and utilize GQC6 Quality Control Software for advanced data analysis, trend tracking, and professional report generation.




• Wide Compatibility:

  Suitable for semi-gloss surfaces (60° angle) with a measuring area of 9×15 mm, covering a gloss unit range of 0–300 GU. Applications include automotive finishes, plastic products, metal coatings, printing surfaces, stone materials, and paint layers.




Technical Specifications

• Model: HG60




• Angle: 60°




• Measuring Range: 0–300 GU




• Accuracy: Meets JJG696 secondary glossmeter standards




• Chromaticity Standard: CIE 1931 under CIE-C light source




• Data Storage: 1000 groups (basic mode)




• Interface: USB




• Languages: Chinese/English




• Operating Conditions: 0–40°C, ≤85% RH (non-condensing)




•

Applicable Industries

The HG60 is widely used in sectors requiring consistent surface gloss evaluation, including:

• Automotive: Coatings, interior/exterior trim




• Plastics & Polymers: Consumer products, components




• Paints & Coatings: Quality checks for finishes




• Printing: Paper, packaging, and decorative prints




• Metals & Stones: Architectural materials, decorative surfaces




• General Manufacturing: Furniture, electronics, and consumer goods




Optional Accessories

A miniature thermal printer is available for portable, computer-free printouts of measurement data, ideal for onsite inspections and instant reporting.

Why Choose the HG60?

The HG60 combines affordability, accuracy, and ease of use—making gloss measurement accessible without compromising on professionalism. It is an excellent tool for quality controllers, production engineers, and lab technicians who require fast, repeatable, and standards-compliant gloss readings. With its intuitive interface, durable construction, and versatile software support, the HG60 helps industries maintain high product quality and meet international gloss standards efficiently.
