MAS345 & MS8215 Series Digital Multimeters
Dual series (MAS345/MS8215) enable wide - range measurement. Support AC/DC voltage, current, capacitance, resistance, frequency, temperature. Feature True RMS, NCV, backlight, data hold. MS8215 adds auto - power - off & overload protection.
The MAS345 and MS8215 series digital multimeters are professional - grade tools for electrical measurement, ideal for electronics repair, industrial control, and educational scenarios.
These multimeters support comprehensive parameter detection: AC/DC voltage (up to 1000V), current (up to 10A), capacitance (40nF - 1000μF), resistance (400Ω - 40MΩ), frequency (10Hz–10MHz), and temperature (-20°C–1000°C).
Key features include True RMS for accurate AC measurement, NCV (Non - contact Voltage Detection) for safe live wire identification, backlit display for low - light visibility, data hold to freeze readings, and relative measurement for differential value checks. The MAS345 series excels in measurement precision across voltage, current, and capacitance ranges. In contrast, the MS8215 series enhances usability with auto - power - off to conserve battery life and overload protection to prevent damage from excessive input.
Powered by a single 9V battery (6F22 type), both models are compact (dimensions: ~78×186×35mm) and lightweight (~300g), ensuring easy portability. Their user - friendly rotary switch and rugged design make them reliable choices for professionals and enthusiasts alike.
Merged & Simplified Table
Feature | MAS345 Series | MS8215 Series |
|---|---|---|
Voltage (DC) | 400mV–1000V ±(0.5% + 3 digits) | 400mV–1000V ±(0.5% + 3 digits) |
Voltage (AC) | 400mV–750V ±(0.8% + 5 digits) | 400mV–750V ±(0.8% + 5 digits) |
Current (DC) | 400μA–10A ±(1.2% + 5 digits) | 400μA–10A ±(1.2% + 5 digits) |
Current (AC) | 400μA–10A ±(1.5% + 5 digits) | 400μA–10A ±(1.5% + 5 digits) |
Resistance | 400Ω–40MΩ ±(0.8% + 3 digits) | 400Ω–40MΩ ±(0.8% + 3 digits) |
Capacitance | 40nF–1000μF ±(2.0% + 5 digits) | 40nF–1000μF ±(2.0% + 5 digits) |
Frequency | 10Hz–10MHz | 10Hz–10MHz |
Temperature | -20°C–1000°C | -20°C–1000°C |
NCV Detection | ✔️ | ✔️ |
Display Resolution | 3999 counts | 5999 counts |
Backlight | ✔️ | ✔️ |
Data Hold | ✔️ | ✔️ |
Auto-Power-Off | ❌ | ✔️ |
Overload Protection | ❌ | ✔️ |
Power Source | 1×9V battery (6F22) | 1×9V battery (6F22) |
Dimensions | 78×186×35mm | 78×186×35mm |
Weight | ~300g | ~300g |
